Ssupd Meshlicious SFX bracket replacement

I bought my meshlicious second hand and its SFX bracket was missing, which appears to be happening to at least one other person. Enough for me to put in the work! I did not want to miss the support of the rubber block at the bottom of the case so I designed this bracket to replace the original one. The bracket is only compatible with installing the PSU in its lower height configuration.

At least 3x #6-32 UNC PSU screws (those that come with PSUs and PC cases) are required.

Since my PSU is designed to operate at 55°C, I printed my bracket in ASA (glass transition 100°C).

Before installing it, the two parts should be printed and glued together. I suggest printing the parts on non-textured sheet. The spacer should be laid in a way so that its first layer can be glued to the bracket's first layer. This ensures two flat surfaces optimal for gluing with Loctite superglue or similar plastics glue. The provided project file is set up as such.

After gluing, use the screws and thread them into each corner hole of the print. This cuts in the thread and makes installation easier afterwards.

Take out the screws and place the bracket in position. Put two screws back in from within the GPU area and one from the PSU area.

Install the PSU.
