WERA Screwdriver Magnetic Mount

Magnetic inserts to allow the included WERA Screwdriver wall mount to be attached to metal surfaces using magnets.

You will need to print 2 of the small parts and 1 large. They should press-fit into the voids on the back of the holder. Due to print orientation (blank side DOWN), they are incredibly strong and only require 10-15% infill. They can be removed by pushing a finger or screw driver into the bottom side where I've used the small screwdriver stops to design the block's depth. Optionally there is a little angled tab on the face that can be pryed using a small screwdriver or spudger

Magnets are 20x10x2.75mm from Amazon, however the included fusion file is almost fully parametric and allows this to be easily changed.

EDIT - I've uploaded models using circular magnets with a radius of 10mm and depth of 2mm. STEP and f3d files are available for remix/edit

Printed on eSun Orange PLA+; 2 walls with a .6mm nozzle (the low layer height was a personal test, and I think you could go up to .36mm (.24mm on a .4mm nozzle) considering the simple geometry.

I tested this with single magnets on each block. It was front heavy until I added up to 6 magnets, however your results may vary. The assembly should require no glue, but if your printer tolerance is any greater than .2mm, you could wrap the perimeter in a layer of masking tape before tapping into place
