Hakko Smoke Absorber Shroud

A shroud to add some ducting to the Hakko Smoke Absorber, when used in the face-down mode.
1
8
0
76
updated September 17, 2024

Description

PDF

This is a shroud for the Hakko Smoke Absorber when used in the face-down position.

Problem: I found that in the face-down orientation and with an Amscope microscope stand, it couldn't get close enough to capture the solder smoke most of the time.  I'd usually need to cup my hand to guide the smoke in, and even then, this wouldn't work all the time.

It's meant to be taped down to back with a little bit of thin, double-sided tape.

Unfortunately, this requires a little super-glue to put it together, as it was much easier just splitting this into multiple parts than trying to find a thin, easy-to-print option that didn't require more material in supports than the model itself.
