Logitech Flight Switch Desk Clip

This is a basic clip for mounting the Logitech Flight Switch Panel to the edge of a desk.
2
21
0
120
updated September 2, 2024

Description

PDF

This is a basic clip for mounting the Logitech Flight Switch Panel to the edge of a desk.  The desk originally used for scaling is 27mm deep, the file would need to be adjusted for anything else.
Included is a super simple version that doesn't have the upper pieces to help support the top from rocking around when flipping switches, especially the landing gear lever.
I printed mine at 0.20 layer height, 10% infill, a brim for adhesion, and no supports were needed. I am using an ender 3 v3 se with anycubic grey PLA.

This item was created by me in a mix of fusion360 and Solidworks 2023. I made it because I wanted a way to keep my Logitech Flight Switch Panel on my desk and relatively secure while playing sims in VR, it works pretty well for that. It's not super well optimized, the cutouts on the larger model were more or less just shoving triangles through it and clicking exclude, but hey, it functions.
It's the first model I have ever designed and actually created myself, previous models I have made had been 3d printed but either not in their entirety or by others.

Hope you enjoy!

Model origin

The author marked this model as their own original creation.
