Breadboard or jumper cable holder, Skadis compatible

You got breadboard cables lying around in an entagled mess? Me too.

This cable holder comes with twelve cable slots and four sections for different cable lengts:

• 80 mm
• 120 mm
• 160 mm

Put it on your desk or mount it on your Skadis wall board with the included hooks.

This was designed to be printed on a Prusa Mini.

My print configuration in Prusa Slicer:

• Layers at 0,2 mm structural
• infill 30%
• orientation: flat on the print bed, not upright!
• support on the printbed, applies only on to little spots
• some orange PLA

Material consumption:

• comb grids: around 10g each, 40g total
• rails: around 4g each, 8g total
• hooks: around 2g each, 4g total

Assembly:

• print 4 comb grids
• print 2 rails
• stick the combs onto the rails. I didn't use any glue, depending on the dimensional accuracy of your printer you should glue them together
• print 2 hooks, simply hang the assembly on the mounted hooks

Enjoy.
