IKEA FABRIKÖR Door Latch Lock Replacement

This latch replaces the original IKEA FABRIKÖR lock barrel assembly. It uses the original retaining clip and cam. Obviously it does not retain the keyed locking function.

The following parts will be needed to secure the cam:

1. (1x) M2 x 3mm heat insert
2. (1x) M2 x 7-8mm flat head screw

Printing Notes:

• Print inner portion with the flat side on plate (so that the long handle portion is facing upward). This provides additional strength.
• Print outer insert with large end on plate
• 90-100% infill is ideal.
• 0.16 layer height
• PETG or ABS is preferred, but I used PLA without issues (although I can't comment on longevity)
• No brim required
