Bike brake cover to protect disk brake during cleaning, remix for more protection

I have added an additional cover with magnets to protect the disk brake.
16
82
0
450
updated August 30, 2024

Description

PDF

I took the great design by @donnyturns of a disk brake cover to protect the disk break from contamination from the grease residue or aggresive products while cleaning the bike.

I added an additional part to offer full protection, and then added magnets to both of them to make it easy to assemble and dissassemble.

  • prints in place
  • need to print each separately, since the main part takes nearly all print bed
  • requires 20 magnets of 6x2mm size, and glue

(make sure to put the magnets in the correct orientation if using glue)

Prints without supports, like the original one.

Model origin

The author remixed this model.

Differences of the remix compared to the original

I have modified the original model to add magnets, and added my own part to complete a 360 degree protection
