Wall-mounted Bottle Holder

A simple wall-mounted bottle holder held in place by screws. Easy to disassemble. Requires separate screws to mount.

This model comes in 4 parts for easy disassembly and cleaning, as I originally created this as a simple holder for squeeze bottles of wood glue. Minimal supports required for printing, and even that can be optional depending on your printer's overhang capabilities. The bottle-holder and base sections are inserted into the notches in the wall-mounts prior to screwing in the wall-mounts, holding them against the wall to secure them in place. Remove one wall-mount to allow the holder and base sections to be removed again.

I upsized the mounting holes by about a 1-2mm tolerance for a Number 8 size, 5/8" long wood screw, though length doesn't really matter much so long as the screw can handle a ½" thick plate.  This model is designed to loosely hold bottles 2 inches in diameter. The holes for the bottles are 2.5" in diameter. The bases are filleted to help center the bottles, with an outer diameter of 2.5" and an inner diameter of 2". Total assembly size is 12"x3.5"x5" volume.

Either the base or bottle-holder plates can be removed as needed, such as if you would need to increase the distance between the two plates and mount each separately. Extra wall-mounts have also been added for specifically this purpose that will only hold either the base or bottle-holder plate, though they might not be as stable due to their shorter length and single screw mounts.
