Small improvements to the MFNano filter for an easier time assembling it
Tags
The author remixed this model.
Differences of the remix compared to the original
After assemblying my MFNano filter I noticed some small things that could be improved, so I took some time and updated the original design with the following changes:
6x3 magnet holders
- 0.05mm deeper
- slightly enlarged the magnet hole to allow dealing with poor manufacturing tolerances
- added hole to allow glue to escape and not act like a spring pushing back on the magnet
- reworked most geometries as the cad had them slightly offset between eachother. This is most probably just an issue with fusion360, but I had to fix them to ease changing the design
plenum body
- enlarged the fan housing by 0.15mm to have an easier time with largers fans (like GDStime)
BOM and assembly guide remains unchanged, so check the original project for guidance
