HP Mini Flex IO V2 mount plate for M.2 a/e RTL8125B 2.5Gbit Network Adapter

This is an original adapter plate to allow mounting an Ali-Express 2.5Gbit RTL8125b adpater to the HP Mini's FlexIO V2 slot

Designed it to mount the socket upside down so it better aligns to the slot at the rear of the HP mini.  Also have not put any recesses on the main plate screw holes as they should bite down on first fit to keep it snug.

Its a bit quick and dirty, but seems stable and strong enough.

Please note: there are several variations of this network adapter on ali-express.  Be sure to get the one that has the pinouts on the main board that are below the M.2 Mounting screw otherwise IT WILL NOT FIT HP Mini G6-G9. I have added a stock photo of module for reference.

https://www.aliexpress.com/item/1005006925406656.html

Printed in PLA 100% infill

If I get bored I might add a blanking plate for the rear of the HP Mini but for now this gets the job done.
