PiKVM DIY Case (WIP)

Case for PiKVM DIY


IP-KVM OpenSource Project PiKVM. (https://pikvm.org/)

Note: This model is still a work-in-progress.

This is made as a concept. Printable and works, but some design changes are needed.
Chages has been made, but still in testing. Few clearence problems. Might do a “complete” redesign (2024-08-10).

Parts needed:

• Raspberry Pi 4
• HDMI to CSI Adapter
• USB-C/PWR Splitter
• 4010 5v fan (optional)
• M2.5 heated inserts
• M2.5 screws (+bolts for fan)
• Short USB-C cable (power+data)

Parts note: M3 inserts and screws works for top and fan.  M2.5 for electronics.

v1.1

v.1.0

Changelog:

• v1.0 - Version 1.0 (concept)
• v1.1 - Redesigned top. HDMI to CSI board now screws to top. (2024-08-07)
• v1.1.1 - Small change to top. Fan position moved to allow access to all pins. (2024-08-08)
• v1.1.2 - Fan position moved (again). Better clearence CSI connector. (2024-08-10)
