Alastor's Staff - 4-Parts Threaded Pole, Collapsible and Compact Pole

Alastor's Staff for cosplayer or collectionists. One version has got a collapsible pole that can be shorten for transportation and one version has got a compact pole.

Assembly instructions:

Collapsing version:

You'll need to print all the selected parts once, I'd suggest using the color in each file's name.
You'll need to glue together these parts:

• All the “Flame-Microphone” files (the "Eye" might be just a snap fit)
• make sure to place all the pole parts together and check if the collapsible system works well. The parts of the pole have an upper and a lower part because they are slightly conical. If the parts don't have enough friction you can add a layer or less of insulating tape to the top of each part to increase friction and make the pole more rigid. Once the system works well you can proceed to glue the following parts.
• 6th cap with 6th
• 1st cap with 1st

The full top will connect to the pole to the foot with the threads.

Compact version:

You'll still need to print all the parts you need once, I'd suggest using the color in each file's name.
You'll need to glue together these parts:

• All the “Flame-Microphone” files (the “Eye” might be just a snap fit)
• Compact Pole with Compact Pole Cap


The rest will connect with the threads.


Troubleshooting:

All the parts printed perfectly and with a perfect fit with each other, but some people had some problems, so I included the .f3d file for some slight corrections.

All the credits above goes to Andrea Loddo for making this fantastic model.

----------------------------------------------------------------------------------------------------------------

Threaded Pole version:

Since the collapsible version was not sturdy enough, I decided to create a version of the pole that can be screwed together in four parts, making it easily portable. It can be disassembled and transported conveniently in separate sections.

Ho diviso in due parti la fiamma aggiungendo degli innesti di centraggio per l'incollaggio delle due parti e anche per la centratura del microfono
