Lynx N1

This is my remix of the Orion Blasters Lynx modded to fire N1 darts using my magazine design linked here

https://www.printables.com/model/945546-nitrogen-series-15rd-magazine

You will need the cut version. Here is a link to Vile Mods dart cutting jig

https://www.printables.com/model/922026-nerf-n1-dart-cutter

This replaces all the printed parts from the receiver back minus the grip. I ncluded all the files necerssary to print a complete blaster but if you have an existing Lynx you can just print the spacer, turnaround, magwell, stock, pusher, plunger1 and plunger2. The only additional harware needed are 2 6mmx7mm ball detents linked here for magazine retention

https://www.amazon.com/dp/B08SWDZ8ZG?psc=1&ref=ppx_yo2ov_dt_b_product_details

For a barrel you will need a 16mm x 15mm barrel. I would suggest around 50cm long.  I cut one of these down but you can use aluminum or polycarbonate if you can find it long enough

https://www.amazon.com/dp/B0777HCKFB?psc=1&ref=ppx_yo2ov_dt_b_product_details

I tried using 5/8 x .029 brass as a barrel but the darts were too tight to fire consistently.  I found the best spring to be the k25. The cut darts weigh the same as regular half darts so performance should be comparable.

If you are interested in the hand guard pictured on my build (white) it's here

https://www.printables.com/model/704820-slynx-shroud-modified-for-lynx

Included as well is the ergo stock and buttplate pictured on my build.

This is a new dart platform. While I have tested my own build extensively there may still be some unexpected kinks or issues. I am including the step files for you to tweak the design as you see fit or you can comment here and I will try to resolve any issues.

replaces the spacer, plunger tube, turnaround, dart guide, stock, magwell, and ram
