Universal Intercom Clamp

Required parts

The bolt / handle is not a 3D model, and is not included for part strength reasons. you need to order the handle separately, which is this one for USA: https://www.xump.com/science/quick-release-plastic-c-clamp-2.cfm

and this one for EU:

https://www.amazon.nl/TOPEX-12A380-Topex-Lijmklem-50mm/dp/B01MRA3L7U/ref=asc_df_B01MRA3L7U/?tag=nlshogostdsp-21&linkCode=df0&hvadid=704598979670&hvpos=&hvnetw=g&hvrand=3348147287202281965&hvpone=&hvptwo=&hvqmt=&hvdev=m&hvdvcmdl=&hvlocint=&hvlocphy=9064713&hvtargid=pla-2320932577626&psc=1&mcid=ffde7d8ab5fe3a919ab81e1b9e9f4a60&gad_source=1

If you want to buy the complete clamp from my business, you can do that on my Etsy with worldwide shipping: https://www.etsy.com/nl/listing/1737888450/av-comms-holder-and-clamp-for-greengo

Print settings

Best is to print it in PETG, so it will withstand heat in a car for example. printing with a brim is recommended. I recommend printing it with 8 walls or more because it takes a lot of forces at the corners.

Description

Universal intercom beltpack holder, the solid solution against your beltpack and headset lying around and taking precious desk space. Hook it onto a flightcase handle, flipped or not. clamp it onto a table or hook it behind an edge. hang the headset over the beltpack, and even flip the handle 90 degrees for clearance for your legs under a table. Suitable for all AV Beltpacks with a belt clip. Suitable for:

- ClearCom Freespeak and partyline
- GreenGo BPX and WBPX
- Riedel Bolero
- Hollyland Solidcom
- RTS, ASL, PunQtum and many more...
- Every beltpack with a beltclip up to 12mm(0.45") thick and up to 54mm(2.1") wide.

The maximum thickness of a table or table leg is 7cm(2,75") to be able to on clamp it. The hook on top of the holder is used to hang it onto a flightcase handle with the maximum thickness of 15mm. The notch on the top part where you can hook it behind an edge is 20mm wide, and will work perfectly on a tongue and groove of a flightcase or for example a wooden board.
