Logitech c270 Mount for Voron

The camera mount is for mounting a Logitech c270 camera on a Voron2.4 or Trident. I put the camera in the middle of the top back extrusion. But it could go in any of the top extrusions.

BOM

1. M5x10 BHCS x2
2. M5 T-nut or hammerhead nut x2
3. M3x20 BHCS x1
4. M3 nut x1

Assembly

Prints without supports. You will need to remove the mounting arm that comes with the camera. Then simply insert the M3 bolt through the print and camera and attach the M3 nut. Tighten the nut to keep the camera in place, loosen to adjust angle. Lastly mount to your extrusion with the M5 bolts and T-nuts
