M.2 quick connect for Opi5

I finally got a M.2 SSD for my Orange Pi 5. I did not like any of the standoff hardware I had to hold the SSD down, so I created this to make it easy to install and remove the SSD. It will fit in the case I made with a little gap and not hitting the bottom of the case.

I made this specifically for the Orange Pi 5 M.2 mounting holes. It may work for other things too.

It's best to print with a Brim to hold it in place. Supports helps the spacer print better. It should snap into the hole with a little effort. Then put in your M.2 SSD and turn it 180 degrees, and all is good.

Print Settings

Printer Brand:  Creality

Printer:   Ender-3 S1 Pro

Rafts:  No

Brim:  Yes

Supports:   Yes

Resolution:  0.12

Infill:  100

Filament:  Creality PLA Black

How I Designed This:

in FreeCAD 0.21

Category: Computer
