Moonlander Sound Dampening Foam

Cut files for noise reduction foam for the top of the Moonlander keyboard.

I cut this using the Snapmaker 10w laser cutter with Lightburn.

Cut settings were

• speed 1800mm/m
• power 90%
• passes 1

This cut setting worked for 2 types of foam that I used:

• Sound deadener foam
• Keyboard foam

You can also see in the photo that I put keyboard switch pads below my switches.

I've also included STLs of 3mm versions of this (I think that's the amount of space above the PCB) if you want to try and print a TPU version, but I really don't think that'll turn out well.

Unfortunately I don't have a good microphone available to capture the sound difference before/after adding the foam.
