MKH416 shotgun mic shock mount
Shock mount for the MKH416 (or similar diameter) shotgun microphone. Uses lyre-style suspension.
5
23
0
188
updated July 23, 2024
Description
PDFNeeded to eliminate bass transmission through my mic stand, so modified ERKARK's lyre design to work with the MKH416.
Friction mounts to an On Stage mic stand.
Use TPU for the mic collars and stand connector. PETG for the lyre shocks.
Hardware required:
- M5x8 bolt
- M5 nylock nut (regular should work, not tested)
Tags
Model origin
The author remixed this model.
Differences of the remix compared to the original
Modified for snap-fit assembly and mounting ability
