This is a Miter/Mitre box that I created myself in OnShape which I've used to generate a couple different Miter box versions in different dimensions depending on the need. To go along with the box there are cam pins with hooks included which can clamp down the 2x4s being cut both either when laying them on their face or side.

Each of the Miter Boxes feature markings for cutting at a 90 degrees, 45 degrees, and 22.5 degrees.

Available Models

Currently there are the following configurations available:

Miter Box for general use, can fit a 2x4 either on face or side with a row of clamp holes available to lock it in place
- Filename: Miter Box - 100mm wall height - 103mm internal width.stl
- External Dimensions: 123mm W x 200mm L x 110mm H
- Blade Clearance: 1.2mm
- Clamp Hole Diameter: 6mm (with 6mm border)
Miter Box for cutting 2x4s on face with a row of clamp holes available to lock it in place
- Filename: Miter Box - 50mm wall height - 103mm internal width.stl
- External Dimensions: 123mm W x 200mm L x 60mm H
- Blade Clearance: 1.2mm
- Clamp Hole Diameter: 6mm (with 6mm border)
Miter Box for cutting 2x4s on their side with a row of clamp holes available to lock it in place
- Filename: Miter Box - 100mm wall height - 52mm internal width.stl
- External Dimensions: 72mm W x 200mm L x 110mm H
- Blade Clearance: 1.2mm
- Clamp Hole Diameter: 6mm (with 6mm border)

Print Settings

I used the following Print Settings for mine, feel free to adjust as you want though.

Infill: 15% (any setting you want will do)
Supports: None (there shouldn't be any need for supports when printed in the orientation the files are in)
Infill Type: Adaptive Cubic (any setting you want will do, I prefer adaptive cubic for these)
Walls: 3 (2 walls works too, but I find the part to be more sturdy with 3)

If there's other configurations this would be helpful in for you send me the dimensions in the format above and I can generate it and add it to this post as well.
