40mm silent fan Adapter for 1U servers (shorter version for 28mm fans)

0 reviews
8mm shorter version to accommodate 28mm-Fans like the Arctic S4028-6K/S4028-15K or other typical 1U server-fans.
3
20
0
224
updated August 8, 2024

Summary

PDF
8mm shorter version to accommodate 28mm-Fans like the Arctic S4028-6K/S4028-15K or other typical 1U server-fans.

Tags

fan 40mm adapter 28mm server

Model origin

The author remixed this model.

40mm silent fan Adapter for 1U servers (Supermicro, Intel, EMC)
 by DanAndersen


Differences of the remix compared to the original

This version is 8mm shorter than the original, so it will work for 28mm deep fans replacing 56mm ones. Fans that shoud work are e.G.

  • Arctic S4028-6K (very silent)
  • Arctic S4028-15K (not so silent)
  • Supermicro FAN-0100L4 (comparatively silent, most quiet Supermicro-Fan in 40mm)
  • Supermicro FAN-0154L4 (relatively loud)
  • … or other typical 1U server-fans for low-load-applications.

However, any 28mm-fan should give you an enormous amount of more pressure than 20mm fans, even the S4028-6K ones…



By pure coincidence, 2 of these adapters back-to-back and a pair of cableties work excellently as constrained cable-tunnel in supermicro-cases (sc116 in my case, see pictures).
