2020 Aluminum Extrusion Plates

Part of the same family of parts as my corner bracket parts, I introduce my set of 2020 aluminum extrusion building plates. I have included a few varieties, they were all modeling OnShape. There will be more of these 2020 building block type parts to come!

General plate specs:

• Slot extrusions for guiding/holding the 2020
• M4 Screws w/ countersink
• Quick print

UPDATE 6/27/2016 Added two more plates both for joining two pieces of extrusion together perpendicular to each other, these parts have "PD" in the name.

UPDATE 1/23/2020 These parts/this thing is now obselete!!! Newly updated version of all these parts plus new ones at this new thing: https://www.thingiverse.com/thing:4117326 come check them out and print them, tell me what you think!

Print Settings

Printer:

Maker Architect (Replicator 1 Clone w/ Heatbed)

Rafts:

Doesn't Matter

Doesn't Matter

Resolution:

0.2mm

40%

Notes:

Recommend Printing at 0.2mm layer height, 40% infill and 50mm/s for decent quality.
