Ender 3 Bedside LED Bar

This LED light bar is designed to slot into the left hand 4040 extrusion of an Ender 3 or Ender 3 Pro. It accepts 8mm…
2
10
0
95
updated July 15, 2024

Description

PDF

This LED light bar is designed to slot into the left hand 4040 extrusion of an Ender 3 or Ender 3 Pro. It accepts 8mm width LED strips.

I found that with only overhead LED lighting, the hot end cast a shadow and prevented me from seeing what was happening on my first few layers when monitoring via Octoprint.

This solution lights the area under the hot end sufficiently.

There are two options for the "Upright" file, one near and one far from the bed. The "Upright Far" file keeps the LED bar totally away from the bed. The "Upright Near" file brings it closer, and the LED bar itself may overlap the bed depending on your orientation. But it should clear the bed regardless of choice.

Print Settings

Printer Brand:

Creality

Printer:

Ender 3 Pro

**Rafts:**

Doesn't Matter

Supports:

Yes

**Resolution:**

0.12

Infill:

20%

Notes:

Printing the "LED Bar" standing upright (90 degrees) with supports set to only "touching build plate" worked well for me.

The finer the detail in which you can print "LED Bar", the better. "Upright" and "Rail" require less detail.

"Rail" prints best with it's flat side to the build plate, and with supports.

Post-Printing

Assembly

Glue "Rail" and "Upright" together on their flat faces.
