Bronica GS-1 Viewfinder Bottom Cap

Bottom cap for any Zenza Bronica GS-1 viewfinder, including the GS-1 Prism AE Finder, and the GS-1 Rotating Prism AE Finder. Originally I made this to be printed with TPU, for flexibility, and it certainly works, but it's not very attractive. I found it works equally well with more rigid PLA, and I expect it would work well with even more robust ASA. I printed it with a silk PLA for the purposes of the photos. (Though it certainly adds a bit of 80s pro photo gear look, as some manufacturers were putting gold flair on their gear at that time!) I added the logo/text to help indicate the orientation of the cap (text is the front of the finder).

Print Settings

Printer Brand:

Snapmaker

Printer:

Snapmaker 2 A350

No

Supports:

Yes

.16 layer height

Infill:

15

Notes:

I used support for the little overhangs, but the supports didn't really "hold," but it didn't matter, because each one I printed came out perfect. If you choose to use TPU, be prepared for a lot of cleanup - lots of strings.
