ESP32Cam-Enclosure

A simple small enclosure for an ESP32Cam with tripod mount.

It has no opening or room for the SD-Card as i don't use one.

The light can only be used as an indicator because the enclosure has just a little hole for it. The position and depth of the led would require a funnel like opening wich expands to the side. That would ruin the clean strait look and was not to my liking.

All parts print without support and just snap together and held by friction. Pay attention to position all parts biggest face down on the bed. I printed mine with PLA and it worked without any special slicer settings with 0.4 nozel and 0.2 layer. Don't go to rought to keep the fit and the threading.

The model was created with Freecad 0.21.2.

The fancy artwork on the front is not included in the model! ;-)
