CALIBURN (GER-Edition) "3.stl" // "fixed clamp"-Remix // Update 04.05.25
Update for a more clean and perfected design, function and fitting of CALIBURN.
3
11
0
90
updated May 4, 2025
Description
PDFThanks @CHAOSDRUCKER for this very cool project :)!
Tags
Model origin
The author remixed this model.
Differences of the remix compared to the original
Update 04.05.25:
- adjusted the distance for clamping with more space of 0,6mm.
- changed the position of holes to fit distance of 30,2mm after clamping process
The problem i had with the original: The clamp did not hold the 15mm tube when the srew is turned in maximal :/.
The differences are marked green in the rendered foto of the model
- (clamping function) the clamping function is redesigned to work as aspected
- (fitting) the fitting is set more tight to 15mm - it should slide through and tighten fast when the screw is turned
- (stability & design) made the insertion depth of the nuts bigger so it does not stand out of the insertion hole
