Toniebox Bottom cover MicroSD

This is a replacement part for the bottom cover of Toniebox, but with MicroSD card slot.
8
142
1
949
updated June 30, 2024

Description

PDF

This replaces the bottom cover for toniebox with one that has a slot for MicroSD extension cable.
This is highly helpful if you are working with teddybench or teddycloud:
https://tonies-wiki.revvox.de/docs/wiki/cc3200/microsd-compatibility/#sd-card-extension

The original model has some more information about printing etc.: https://www.printables.com/de/model/367675-toniebox-tottom-cover

The compatible inner battery part with MicroSD reader mount can be found here:
https://www.printables.com/de/model/927961


ATTENTION: Remove the SDCard previously to adding/removing the bottom cover - it slightly stands out into the bottom cover for easier removal.

The object is already aligned in print direction.
Due to the objects architecture it is necessary to be printed with supports from build plate enabled.



Tags



Model origin

The author remixed this model.

Differences of the remix compared to the original

  • MicroSD card slot matches dimensions of mount for: https://www.printables.com/de/model/927961
  • Fixed microSD card slot
