a2212 motor mounting for jet boat

I printed this jet boat and wanted to use an a2212 brushless dc motor. So I designed this motor mount. The 1000kv a2212 motor is more than powerful enough to make the booat go pretty fast.

Required parts:

• a2212 Motor (1000kv or less)
• hollow rod, which fits onto the shaft of the motor (inner diameter: 3.2mm)
• propeller (I used this propeller from thingiverse
• cooling fan (optional)
• This thing (pla is fine, choose between with fan or without)
• Super glue
• The above mentioned jet boat

Assembly guide:

• Prepare your rod and glue on the propeller
• Slide the rod through the hole and seal with grease
• Slide your motor onto the rod
• Mark where motor needs to be mounted (this print)
• Drill holes where motor need to be mounted to
• Mount motor to this print
• Put super glue on the underside of this print
• Insert this print into the boat
• Put super glue on the shaft of themotor
• Insert rod into shaft of the motor
• Asamble jet steering
• I suggest waterproofing your esc with nail polish (not shown in pictures)!

Very easy print:

• No supports
• No build plate adhesion
