Remix Flipper Zero - Minimalist WiFi Dev Board Case (Antenna + GPS + SD)

Models were sliced using Prusa Slicer and printed on a Creality Ender 5 Plus, modified Prusa profiles for PETG (slowed down, higher temp, 100% infill aligned rectilinear, no top/bottom layer).

Filament is Atomic Filament transparent orange.

Thanks to Cody Tolene for his excellent original model.

27 June 2024 - Added a pin cover for safe travelling.

This remix accommodates a number of specific issues with the JCMK dev board add-on:

• The boards are only available currently in the “thicc” version, the circuit board used is too thick to fit the custom designed case. Also, because the board is thicker, it was necessary to widen the slot for the SD card.

• The current add-on board comes with a chonky ceramic GPS antenna, I redid the top of the case to handle it.

• I chose not to use the external WiFi antenna, so this version does not have that feature.

• Not a fan of little buttons, I changed the front panel to use two print-in-place button pressers.

• I printed my case in PETG, so I thickened the front and rear of the case to make it a little more sturdy.
