Yet Another SAE Connector Cap - Battery Plug

I didn't like the other ones I tried, so here's another one
2
35
0
151
updated June 22, 2024

Description

PDF

I tried some other caps out there, but didn't like them, so I drew a new one from scratch.  Note that there seem to be plugs with different depths, so this will fit some but not all.

Made two versions:
rev A: 0.46in height (see image)
rev B: 0.41in height ( see image)

Print with TPU 95 and your settings of choice

Tags



Model origin

The author remixed this model.

SAE Connector Cap with Leash
by RLovrin1 (cults3d.com)

Differences of the remix compared to the original

Took inspiration from the linked model, but redrew from scratch and changed everything.  Added chamfers and fillets, changed shapes and dimensions to better fit the plugs I have.
