R50 Jig Insert
A 50mm insert for the Corner Radius Jig from @Warlogh_1253543. Includes STEP and Fusion 360 files for easy editing.
2
28
0
139
updated June 16, 2024
Description
PDFA 50mm (~1.97 in) radius insert for the Corner Radius Jig by Warlog. This is the largest possible radius for that jig without making the full arc non-continuous.
Included some extra files for easier remixing than the original model.
The settings for the thread that worked for me were:
Insert printed in red PETG from SunLu, with weird artefacts from ironing. Base piece printed in some old no-name copper PLA.
Tags
Model origin
The author remixed this model.
Differences of the remix compared to the original
The insert was modeled from scratch based off of the original's dimensions, so not a strict remix.
