Chube Ratrig Toolhead (V-Core4) now with idex support!
Looking for more flow, than the standard Rapido 2? This toolhead brings the addition of chube to your V-Core 4!
29
154
0
1640
updated May 7, 2025
Description
PDFChube is the greatest and latest hotend in the 3d printing market, featuring a staggering 42mm of meltzone! Chubes packaging doesn't just help create a massive meltzone; it also has a lot of rigidity thanks to the shroud design.
These plates will soon be coming to https://lukeslabonline.com/
Thanks to Hunterprime on discord for testing + the picture.
Tags
Model origin
The author remixed this model.
Differences of the remix compared to the original
Requires:
- A new top plate (Lazer cut or Milled)
- Chube air
- A different Front, back and duct printed
- 6x M3x12mm FHCS
- A ~23.95mm long PTFE tube (MAKE SURE ITS COMPRESSING)
What else changes?
This mod allows the option for the Lgx Lite Pro
Lgx lite pro requires:
- 1x RR_Toolhead_LGX_Lite_Pro_Plate (Lazer cut or Milled)
- 1x VC4_Toolhead_LGX_Lite_Pro_Toolboard_Vertical
- 1x M3x30mm SHCS
- ~26mm long PTFE tube (MAKE SURE ITS COMPRESSING)
Beacon has a offset change to 27.3mm
Just add to the bottom of ur printer.cfg (with ratOS)
[beacon] y_offset:27.3
