Abstandshalter und Regalbefestigung

um ein Regal zu befestigen, habe ich diesen Halter entworfen. Nun hat es einen sicheren Stand und liegt nicht direkt an der Wand an.

Der Abstandshalter hat eine gr\u00f6\u00dfe von L\u00e4nge 70mm, Breite 25mm, Tiefe 30mm, der Lochabstand betr\u00e4gt 30mm und die beiden Bohrungen haben einen Durchmesser von 5mm. Die Schraubplatte hat die selben Ma\u00dfe, hat eine Tiefe von 5mm und die Schraubenl\u00f6cher sind gesenkt (3mm).

Ich habe jeden Halter mit zwei 6mm D\u00fcbel und zwei Senkkopfschrauben 4,5mm x 70mm befestigt.

Spacer and shelf mounting

to mount a shelf, I designed this bracket. Now it has a secure stand and does not lie directly against the wall.

The spacer has a size of length 70mm, width 25mm, depth 30mm, the hole spacing is 30mm, and the two holes have a diameter of 5mm. The screw plate has the same dimensions, has a depth of 5mm, and the screw holes are countersunk (3mm).

I mounted each bracket with two 6mm dowels and two 4.5mm x 70mm countersunk screws.
