Arduino Case with Lid

The case is made with the purpose of having all pins connected at the same time and then attaching them on the holders
0
17
0
183
updated June 2, 2024

Description

PDF

The lid and sides of the case have pin holders so that you may put all the connected pins into them, the idea is to never have to connect and disconnect pins on the arduino. All the pins will be connected at all times and you will easily be able to connect and disconnect new connectiions from the pin holders. Obviously you'll have to either color code or remember the pin# of each. The case is specifically made to have screw fittings for specific dimensions, if you contact me i can alter the distance to fit your purpose.

Model origin

The author marked this model as their own original creation.
