Raspberry Pi 4 quality case, with VESA mount (V3.3)

Raspberry Pi 4 case, with VESA mount (V3.3)
4
43
1
198
updated June 3, 2024

Description

PDF

Just another case for Raspberry PI 4 without active cooler (may not needed).



Slightly everything holds together without any screws.

That is nice if you must open and close it many times.

There are two types of cover. One is without screws at all.

The other I recommend the two screws in the front (2 x 2.5mm/8mm, countersunk ).

The other four screws on top are 2.0mm (Notebook screws).



A wide opening on the back allows to remove the cover and also the handling of the SD card.



Thank you Matthias, for your ideas to improve that model.
