Gantry stand / stopper for the Creality Ender 3 v2

A stand I designed to stop the gantry from falling down (Z axis) when the motors are off. It slides into the v-slot.
4
15
0
201
updated June 9, 2024

Description

PDF

Noticing that many users encounter the issue where the gantry of their Ender 3 v2 falls down when the motors are off (because it only has one Z screw), I designed this stand that slides into the v-slot of the printer (see photos).

The gantry can rest on it until your next print!

When ready to print, just move up the gantry a bit to free the stand, and slide it towards you (just to the front of the printer and away from the gantry range, no need to remove it completely between prints!).

It prints flat on the larger side (see slicer picture) with no supports :)

Printed mine with PLA, 0.2mm layers, 20% infill
