This is an open-source Plastic Antweight combat robot, intended for the SCAR component kits available from Turnabot and Team Malice. This and other community designs can also be found on the Team Malice website.
It placed 4th overall at Society of Combat Attack Robotics (SCAR)'s May Plastics Pandemonium (4 May 2024) as well as at Nexus Knockout! It placed 1st in Build Fight Fun! at InfinitiCon Tallahassee and in Robot Renegades Summer Showdown as Killer Parakeet by Helen Claudio of Firewolf Robotics!
The design of this project is my own work, however it is heavily inspired by the full-combat Antweight “Night Force”, which in turn is inspired by the BattleBot “Bite Force”.
Warning! All combat robots are inherently dangerous! Handle LiPo batteries and powerful motors carefully.
Follow interactive assembly instructions here!
Buy the drive kit from Turnabot! Weapon parts available separately.
An AFDS2A compatible 3+ channel radio is also required, such as the Flysky FS-i6 or one of the RadioMaster 4-in-1 radios.
All parts should fit on any printer 120x120mm or larger. Overture Super PLA, Fusion Filaments HTPLA+, or Duramic PLA Plus recommended for all parts.
| Qty | Part | Print Settings |
|---|---|---|
| Note: All prints use .5 mm line width for all perimeters | ||
| 1 | Frame | 61.3g @ 10 wall, 10 top/bottom |
| 1 | Motor Upright | 18.2g @ 8 wall, 20 top/bottom |
| 1 | Bearing Upright | 22.3g @ 8 wall, 20 top/bottom |
| 2 | Armor | 27g @ 15 wall |
| 1 | Lid Left | 6.5g @ 3 wall, 4 top/bottom |
| 1 | Lid Right | 6.5g @ 3 wall, 4 top/bottom |
| 1 | Lid Center | 4.5g @ 3 wall, 4 top/bottom |
| 2 | Forks | 7.6g @ 20 wall |
| 1 | Wedge | 28.4g @ 20 wall |
| 1 | Spinner | 81g @ 2 wall, all top/bottom (100+) |
| 4 | Printed wheel | 2.6g @ 3 wall, 4 top/bottom, 20% honeycomb |
| 1 | Wheel Spacer Tool | |
Note: There are two versions of Upright-Bearing, one for a standard M5 Hex Nut, and one for a Thin Hex Jam Nut
| Qty | Part | Use | Source |
|---|---|---|---|
| 4 | Turnabot N20 1400RPM@2S | Drive motors |
|
| 1 | Malenki Nano Integrated HV | ESC and RX | |
| 4 | Lego 30.4mm x 14mm tire | Tires | |
| 1 | 370mAh 2S LiPo | Power source | |
| 1 | Slide switch | Power source | |
| 4 | M3 x 5mm | Motor mounting | |
| 2 | M3 x 6mm | Upright back | |
| 4 | M3 x 12mm | Upright bottom | |
| 2 | M3 x 16mm | Armor side | |
| 2 | M3 x 16mm | Upright/Armor front | |
| 5 | M3 x 20mm | Lids | |
| 2 | M3 x 20mm | Forks | |
| 5 | M3 Nut | Lids | |
| 2 | M3 Nut | Forks | |
| 2 | Heat-set Inserts | Armor sides | |
| 1 | Giant Paperclip or 2.5mm Hex Key | Weapon Lock | |
| 1 | M5 x 12mm | Bearing shaft |
SCAR Weapon Kit currently not available |
| 1 | M5 Hex Nut | Bearing Shaft | |
| 1 | Ready to Sky RS2205 Brushless Motor | Weapon motor | |
| ALT: AKK RS2205 Brushless Motor | Weapon motor | ||
| 1 | BLHeli_s 30A ESC | Weapon ESC | |
| 1 | 105zz Flange Bearing 5 x 10 x 4mm | Weapon bearing | |
| ALT: F695zz Bearing 5x13x4 | Weapon bearing | ||
| 1 | AFDS2A Compatible Radio Controller | Such as FS-i6 or Radiomaster 4-in-1 |
Note: except for the Turnabot N20 motors and Malanki Nano HV, all parts can be purchased from Amazon, eBay, AliExpress, Alibaba, or similar.
16-June-25: Description update, weapon kit no longer available from Team Malice, individual part links added pending new vendor.
22-February-25: Added image showing Emax and rtSky style motors, Emax style drum for F105 bearing, missing rtSky upright
8-February-25: Added wiring diagram
14-January-25: Update v1.1 many small updates, see v1.1_updates.txt for specifics, now supports Emax/AKK style motors, and optional larger bearing. Use fit-test prints to find the optimal fit, print from .stp files using .stl as orientation reference
11-November-24 Added upright with newer CCW style motor compatibility features
23-October-24 New spinner to fit motor variant - will update further once I have some on hand - some file re-organization
13-June-24 Added plane no-text chassis
30-May-24 Initial release. Many updates from beta design that competed in May Plastics Pandemonium
