USB Media Dial

This is a USB HID device that is set up to play media and adjust the volume of your speakers. Underneath the knob is a NeoPixel strip that changes color whenever it’s turned up or down.

You can single-click to play and pause media, double-click to skip to the next track. If you long press, it’ll mute the speaker's volume.

The electronics are housed in our 3D printed snap fit enclosure that features a new design. The knob features a built-in LED diffuser with textured knurling on the outer edge.

We used the filament swap technique to make a multi-material print so there’s no need for a multi-extruder. Just use white PLA filament to diffuse the LEDs.

Code, libraries and assembly instructions are documented in the project Learn Guide links below.

Learn Guide
https://learn.adafruit.com/usb-rotary-media-dial/

QT Py RP2040
https://www.adafruit.com/product/4900

STEMMA QT Rotary Encoder
https://www.adafruit.com/product/5880

NeoPixel Side Light Strip 120/m
https://www.adafruit.com/product/3634

STEMMA QT Cable
https://www.adafruit.com/product/4399
