Mevo Start Handlebar Mount

This is a friction-fit handlebar mount for the Mevo Start wireless camera.

BoM

Item	Thread	Length	Head	Drive	Quantity	Looks like
Bolt	M4	16mm	Button/Any	Hex	4
Nut	M4		Hex		4
Bolt	¼ in. 20 TPI	½ in.	Hex	External hex	1

The mount is held together and secured to the handlebars with metal bolts, which you will need to buy. Assortments of metric bolts and nuts can be found on Amazon.

Assembly and use

1 - Printing

Print all pieces in PETG, whatever resolution, whatever infill, with supports. The gcode is also included.

2 - Attach to the handlebar

Place two M4 nuts in the middle piece and push them to the bottom. Place the middle and bottom pieces on your handlebars, then insert one M4 bolt in the bottom piece. Tighten it so it catches the nut, then insert and tighten the second bolt.

3 - Attach top

Press two M4 nuts in the slots of the top piece. it will be a tight fit and they only fit one way. Fit the ¼ in. bolt in the center of the top piece.

Screw the camera on to the ¼ in. bolt. It should be facing down the length of the top piece when tightened. Press the top into the middle piece until it clicks. Secure with two M4 bolts.

4 - Mounting the camera

Screw the camera on and off the protruding bolt. There is no quick release in this version. You're done!
