Ender 3 Sheet Holder Foot

Summary

This is a quick draft of a foot for the "Sheet Holder Ender 3 - 235mm Plate Glass Spring Steel Mix".

Why? The glass plate is too heavy and I didn't want to create a Cults account ...

I am no engineer ... so just use some little drops of super glue. ;)

Print Settings

• Printer brand: Prusa
• Printer: i3 MK4
• Rafts: No
• Supports: Doesn't Matter
• Resolution: 0.30
• Infill: 5% Cubic
• Filament brand: eSUN
• Filament color: PINK
• Filament material: PLA+
• Notes: These are the same settings as for the holder itself.

How I Designed This

Onshape

I took some measurements of the holder in PrusaSlicer, watched an 8 minute video about Onshape an spent an evening creating this foot. ;)

I added a lot of helping geometry, which was not used at all, to the bottom sketch and played around with extrusions, chamfers and fillets.

I designed a simple support foot around the holders end.
