Case for ESP32 with external antenna

Case for ESP32 with external antenna (works well with ESP32-WROOM-32U).
19
292
3
1287
updated May 13, 2024

Description

PDF

Slightly remixed case for a ESP32 with external antenna (works great with ESP32-WROOM-32U). I have messaged the original author and he's OK with posting new model.

Added ventilation holes on both sides and modified the lid, which is now a 3 mm taller. This gives the chip more air to cool (before the lid was directly on the chip) and the hole for USB is larger.

Tags



Model origin

The author remixed this model.

Differences of the remix compared to the original

I have slightly remixed the case and added ventilation holes on both sides and modified the lid, which is now a 3 mm taller. This gives the chip more air to cool (before the lid was directly on the chip) and the hole for USB is larger.
