Eurorack Suitcase Stand

The "Eurorack Suitcase Stand" is a stand especially for the Doepfer® eurorack suitcase A-100P6 (the small suitcase version with 6U). The whole stand consists of three individual stands and two put-together struts. When the Doepfer® suitcase is placed in the stand, it is tilted back 45 degrees and is easier to use. The whole stand is in that way sized that it fits exactly between the power connector and the rubber feet on the suitcase's back. The width between the two outer individual stands is 29 cm.

The individual stands and the (halved) struts are designed to be printed on a Prusa i3 MK3; the dimensions of each individual stand take full advantage of the depth of the print bed. The struts are printed in two halves and needed to be assembled by pressing together. (Please be careful when doing so - you need pressure to put them together.)

After that the two assembled struts are layed into the cutouts of the three individual stands. The whole stand is stable in itself and need no further screws or something else.

For assembling the whole stand you need:

3x individual stands
4x strut halves

It is recommended to print all stand's parts with PETG because the material is more resilient than PLA. Printing with "0.30mm DRAFT" is perfect (it takes about seven hours for one of the three individual stands...) and 15% infill is also good. Supports are not necessary.

I designed the 3D models of all stand's parts in Shapr3D, spliced them with PrusaSlicer and let them print with my Prusa i3 Mk3. I used Prusament PETG and set the splicer to "0.30 mm DRAFT" as mentioned above.
