I needed a coat hook for my office cubicle and decided I wanted a magnetic one that I could stick to any metal cabinet. It's plenty strong enough for a light weight jacket, and will hold an adult leather jacket as long as you don't brush up against it. Remixed from: https://www.thingiverse.com/thing:4822459

Required parts:
(5) 10x5mm N50 Super Strong Round Rare Earth Neodymium Magnets
(5) Scotch/3M 1/2\" (12,7mm) Bumpers

*Note: The bumpers are necessary to stop the hook from sliding down the metal surface of the cabinet once you put some weight on it.

**Required Steps:
You have to insert a filament color change operation just before the internal magnet pocket tops are covered so that you can insert the magnets during printing.

Print Settings

Printer Brand: Prusa

Printer: i3 MK2S

Rafts: No

Supports: Optional

Resolution: .2 mm

Infill: 30%

Filament:
Purple MatterHackers Build Series PLA Filament - 1.75mm

Notes:

You need to insert a pause or filament color change operation just before the layer that covers the internal magnet pockets so you can insert the magnets.

Post-Printing

Assembly Notes

Stick the 5 bumpers into the holes made for them on the bottom.

How I Designed This

About the design process...

I run Ubuntu Linux on all my home computers. This limits my choices for CAD software so I have taught myself how to use FreeCAD since there is a native Linux version that seems to be getting more stable as time goes by.
