BTT TMC5160T Plus Case

A 3D printed case for the Bigtreetech TMC5160T Plus based on their CNC case. This is a relatively complex and thin print with fully supported holes that stays within the footprint of the board.

This model supports the attachment of a 3010 fan (or any 30*30mm fan footprint), the basic (non-CNC) version of the BTT heatsink, and an optional heatsink for the TMC5160 chip.

There is no additional harware needed to install the fan, only hardware to mount the board + case.

Post-Printing

Removal of the scarificial layer for the mounting holes to the TMC5160T board.
