Worked great. Only complaint is that the shaft is a bit too short. After a few movement the compartment with the pcb starts to rub around the inner frame. I extended it by 6mm and that did the trick.
Thanks !!!
Holoprojector Servo and Astropixels Mount (MK4 Dome)
Holoprojector parts to mount servos and Astropixels to MrBaddeley's MK4 R2-D2 Dome.
65
862
3
3007
updated
September 26, 2025
Makes
Comments
This is the best described project in whole droid community. Thank you so much for it! Great quality!
@Rosch_4134806 Wow! That is such a nice thing to say. I really appreciate that. I put a lot of effort into the instructions (even though I know some parts may still be confusing) in hopes that it would make assembly more accessible.
This solution is great- just need to find the longer servo screws now
Thanks for Sharing, printed for all 3 holoprojectors.
How will you do the lens? I was Looking for 37mm Acryl hemispheres but cant find any online.
@Amnesior_1092071 I believe people use different methods in their builds. Like glass or acrylic lenses, and even hobby/craft cabochons. Anyway, that choice was beyond the scope of what I was providing with these parts. Enjoy!
Thanks for sharing !!!!
Very happy I stumbled upon this. Thanks for sharing your design!
The friction fit doesn't work so well. I'm going to seal it up with hot glue so I can pull it apart later if I need to. (edited)
Thanks for sharing. I'm 3D-printing the parts now and will be testing them out in a few days time, when the M3 6mm bolts arrive.
These are awesome. Printed up a set this weekend, followed the instructions and had zero issues on my MK4 with my Astropixels. The only thing I'm not sure about with my build is I only had 85A TPU. It might need beefier hinges because of how flexible it is compared to 95A. It will likely be a while before I get to test that though.
This is FANTASTIC! Thank you for designing and sharing. Any chance you would consider sharing as a STEP file? I'd like to make a few tweaks
