KS ZS10 In Ear Monitor Case - NEW CORD WRAP

This a rework of the KZ ZS10 In Ear Monitor Case. Featuring a redesigned cord wrap accomodating multiple cord lengths.
22
118
4
419
updated May 2, 2024

Description

PDF

This case features a reworked cord wrap that accomodate multiple different cord lengths.  I hope it addresses the issues some have had with the different versions on the zs10's having different length cables.

I printed this on it's face with 0.2mm layers and 0.5+ lines widths.  Arachne was on.  Overhangs turned out good, but 0.15 layers may look even better.

Tags



Model origin

The author remixed this model.

Differences of the remix compared to the original

The back of the case is scooped out.  There are notches around the perimeter. There are two holes for storing the 3.5mm jack.  The direction arrow is removed.  Fillets have been modified for smooth cable wrapping and better printing.
