ISOLED FLAT12 LED profile corner connector

Corner connectors for the ISOLED SURF12 FLAT aluminum profile.

The profile is available from various retailers in different lengths and 3 colors. (anodized, powder coated white RAL 9010 and powder coated black RAL 9005)

The corner connectors are created with Fusion 360 and fully parametric. I uploaded STLs for a couple different angles and radii.

Let me know in the comments if you need a different configuration.

Printing

Depending on how hot the used LEDs get, filaments with a higher temperature resistance like PETG should be used. Ideally you should use a inflammable material like Prusament PETG V0.

Both parts are designed to be printed with 2 perimeters and a 0.4mm nozzle as well as a layer height of 0.2mm. You can optionally print the uppermost part of the cover with 0.1mm layer height.

The profile part needs support under the pins that extend into the aluminum profile.

The cover works better with supports and a brim. Using the pain-on supports feature with automatic painting works well for the cover.

Compatibility:

Compatible Profiles:

• 112805 SURF12 FLAT aluminum anodized 200cm
• 115571 SURF12 FLAT aluminum anodized 300cm
• 113093 SURF12 FLAT aluminum anodized 550cm
• 113079 SURF12 FLAT aluminum powder-coated white RAL9010 200cm
• 113175 SURF12 FLAT aluminum powder-coated black RAL9005 200cm

Compatible Covers:

• COVER1
  • 112867 COVER1 opal/satinised 200cm
  • 113095 COVER1 opal/satinised 250cm
  • 115573 COVER1 opal/satinised 300cm
  • 113644 COVER1 opal/satinised 600cm
• COVER2
  • 112866 COVER2 clear 200cm
  • 115687 COVER2 clear 250cm
  • 115688 COVER2 clear 300cm
• COVER32
  • 114362 COVER32 black 200cm
  • 115570 COVER32 black 300cm
  • 114363 COVER32 black 600cm
