Joycon Grip with variable sizes

simple joycongrip in different sizes with Switch Gamecard storage slots. Step files of mounting mechanism included(!)
6h 45m
3× print file
0.20 mm
0.40 mm
85.00 g
10
86
1
313
updated July 17, 2024

Description

PDF

A few months ago, I printed another joycon-grip for my own joycons and I was really disappointed. My joycons barely fit. So my goal with this design was;

I tested the grip with my own joycons and was really pleased. I may have overdone it-I hope not. If you run into problems please let me know. You can also store your switch game cards in the joycon grip itself. The larger the size of the grip, the more game cards can be stored in it. The narrow grip has 2 slots for game cards, the medium has 4 and the wide grip has 6.

The grip should be printed upside-down, because I got the best fit and general ruggedness with this print orientation. (If unsure please check the gcode files for correct orientation.)



Do you like the snug fit, but want another type of joycongrip? For you, I have uploaded the attachment-part as a stl and step file, so you can use it in a remix.





Thank you Azra for your help and inputs. I always appreciate your smile in the morning (or whenever I come by).
