Neptune 4 Pro Trash Tray

Hi,

here's my version of a trash tray that I designed for my Neptune 4 Pro. I designed it for my printer where I also use browzzrr's Elegoo Neptune 4 Series Chain system and EntasDisk's Elegoo neptune 4 / pro z-axis stabilizer v2. The trash tray is held in place by two clips. Theres a stand-alone version for the clips and a version that also acts as a chain cable guide.

In the clips theres a slot included for magnets with max. 12 mm x 2,5 mm. Its from an earlier draft where I wanted to use magnets, but it turned that the clips are enough.

Inspiration for the project came from here:
Neptune 4 plus trash(poop)tray with magnets
NEW: 6 styles! Trash Tray (Pooptray) for Elegoo Neptune 3 & 4 Plus

printed with Neptune 4:
- in PLA+
- 0,3 mm layer height
- 3 walls for the clips with 15% cubic infill
- all walls, no infill for the trash bin

Print orientation: clips on the side as in the files & bin with the opening up, so no supports are needed.

Update V1.10 (240509)

updated the clamp and the trash tray after some feedback by David Makes@dTos_1976776

changes:
- redesigned clamp geometry for a bit more grip
- removed the slots for the magnets
- removed the vertical protrusion on the tray sides

See last 4 pictures for new design.

Happy Printing!

I used the geometry of the chain support model (Chain_support_for_Elegoo_Neptune_4_series.stl) as a base for the holder clip of my model.
