Raspberry Pi 3 model A+ case with 3007 fan
The original Raspberry Pi 3 Model A+ has a 3 mm fillet on the PCB corners. The original cad model has a >3 mm fillet…
0
22
0
164
updated
April 24, 2024
Description
PDFThe original Raspberry Pi 3 Model A+ has a 3 mm fillet on the PCB corners. The original cad model has a >3 mm fillet which lead to the corner brushing against the PCB when mounting.
In this remix I have edited the fillets to 2.5 mm to clear away from the PCB and leave a minor clearance.
I also added four bolt holes and a fan hole for a 30x30x7 mm fan.
Category: ElectronicsTags
Model origin
The author remixed this model. Imported from Thingiverse.
Differences of the remix compared to the original
Changed the fillet in corner so that the case doesnt “hurt” the pcb. Also added provisions for a 30x30x07 mm cooling fan.
