Manual Pasta Machine KitchenAid Drive and Mount

This model enables you to drive a cheap pasta machine from amazon like this one https://www.amazon.co.uk/KitchenCraft-World-Flavours-Machine-Stainless/dp/B000RHWI4W/ref=sr_1_7?crid=143R8YSWU8UXE&dib=eyJ2IjoiMSJ9.La1rC0i11FHFyivO3iPWoHYsygmQi3TqXuVXtuXDxwf7XvimPRKkdazxi5Sczl9wXeWwU5EE-uP-xbfnuPEuGL2RX7XrffAQOh7TZxq9P7saXw1G78LwCXQRBuB7iVwrAkhQwtZWK12CQMqHlmLWCvxwcDs3QDQQHG8TTd2Sfabennx_PM2tqKpqpDXVvqdZqx5h6iRFIS6IIZvmDr4KXjK4r4kdDgtckt_hIMmDWCr-D3yFLmz8vLFBSQ9r19o5YqXOPQfjJ9YKNEx2ZJAQuuoMQoSqsPToYp5qYwWMVWQ.bAMQ4qVh6dD36Ql2SSNWi5pYWIiRuqliX4qaW7JBQUA&dib_tag=se&keywords=pasta%2Bmaker&qid=1713706424&sprefix=pa%2Caps%2C1210&sr=8-7&th=1

with a KitchenAid mixer.

You will need to print the 3 parts. I would suggest 5 plus walls for the drive pieces as they need a lot of strength and 50% infill.

You will also need 3 m3 sized heat set threaded inserts, two need placing in the mount part and one in the pasta maker drive.

All parts print without supports as orientated in the 3mf file.

PLA seems strong enough though I haven't run any dough through this yet….

Also I the standard mixing bowl is the right height to support the pasta maker body when connected to the mixer as well which is a bonus!

Added a draft of 1 degree to the square drive to make it easier to insert and a hole down the middle to enable an m3 bolt to be placed into it to connect the square drive part to my pasta machine drive.

Added two holes in the mount for M3 thread inserts, which will hold the pasta machine in place.

Added a piece that drives my pasta machine
